power supply adapter 18volts 400mA
Clink more new product
sofa power supply or dc adapters 29v 2a power pack for recliner
Details
1) input voltage: AC 100-240V 50/60HZ
2) range voltage: AC 90-264V 47/63HZ
3) output Power:7.5W
4) output voltage:18V
5) output currency:0.4A
Safety Approvals
UL/CUL CLASS II 1310 CSA TUV GS CE BS SAA C-Tick KC PSE Rohs FCC LVD EMC CEC MEPS ERP
CB CCC Certifications
Protections
1)over voltage protection: 120%min
2)over current protection: 120%min
3)over protection
4Short-circuit protection: automatic recovery
5Load regulation: ±5%
Environmental requirement
1)operating temperature: 0-40
2)storage temperature: -20-85
3)opera ting relative humidity:595%RH
4) Withstanding voltage: AC 3,000V (minimum), 5mA (maximum)
5Insulation resistance: DC 500V 100MΩ (minimum)
Brand name: BTB
Product Features
1. AC input power suitable for the world
2. Soft-start current can reduce the AC input impact efficiency
3. With short-circuit and overload protection
4. Compact size ,light weight
5. 100%full-load burning test
6. Installed with EMI filter ,minimum wave
| Output Power Range | 5-48V,0-20A,48-200W(also have those models for selection) |
| Input Rated Voltage | 100Vac~240Vac |
| Input Frequency Range | 50Hz~60Hz |
| Input Current | less than 0.5A |
| Input Inrush Current | less than 50A |
| Efficiency | 90%(MIN)at Rated Voltage |
| Leakage Current | less than 5mA |
| Standby power | less than 0.5w |
| Ripple and Noise | less than 120Mv at full road with 20MHz bandwidth |
| Turn On Delay Time | less than 3S (    AC:110V and full load) |
| Dielectric Voltage | A IEC320 three pin input---output(FG)3000Vac one minute |
| Safety protection | output voltage protection (150%-180% rated output current) |
| output current protection (150%-180% rated output current) |
| short current protection |
| Operating Temperature | -10°C - +45°C |
| Storage Temperature | -20°C - +40°C |
| Safety Standard | EN60950-1 UL60950-1 ESD (EN61000 3-3) |
| CAS (60950 ITE/TE) FCC Part 15 subpart B Class B |
| ISO 9001: 2008 |
Welcome to OEM/ODM
Free sample
Sample time : 3-5days
Delivery time:7-10days
Trade terms: FOB shenzhen
Payment : T/T ,L/C,PAYPAL ,Western Union
All product warranty 3 years(One years damage manufacture one to
one exchange.)
Printing you LOGO and stick you modle also ok .
